Anti Gps Blocker Vehicle Mounted Jammer Device / Car Cell Phone Blocker

Introduction

This signal jammer is designed for blocking remote controlled improvised explosive devices used by terrorists.

The Blocker used state-of-art technology for maximum performance and jamming the signals transmission to activate remote controlled bombs.

The Jamming radius depends on several conditions such as transmitter frequency and output power, distance to receiver, and obstacles between, etc.

The system use Broadband Omni-Directional antennas for 360º protection.

Because of the variety of jamming targets and a wide range of uncertainties, we have adopted the more advanced and effective jamming signal modulation method, which will increase the jamming efficiency in each band, so that to provide security protection and ensure the safety of VVIPs.

Product Description

TSL-VM is a High Power DDS Convoy Jamming System, implementing the most effective and reliable RF jamming technology and equipped with a fully-integrated broadband jamming system.

1. Designed with ultra broadband frequency bands, 20MHz-3600MHz (20-6000MHz).
2. 12 modules plug and play design, facilitate for future power upgrading, change and maintenance. Any ruin on the modules never interfere the normal operating of other modules.
3. American Mil-spec standard case, shockproof and drop-resistance, available for the vehicle running in a worse field environment.
4. Up to 20 Frequency Bands. All Jamming Modules Used DDS.
5. Operators are able to regulate the working frequency band and output power of each module through Our software. Configuring a specific frequency band can ensure the internal communication in emergency.
6. System operation can be performed in the driver's console unit. Each module can be ON/OFF. Backup battery or generator system can be optional.
7. Continuously and simultaneously interference to the common used RF signals.
8. Equipped with high power generator to ensure excellent low noise operational capabilities.
9. Integrated backup battery system for continuous silent operation and fast start.
10. Integrated smart active cooling system to make sure the device working continuously.
11. Antenna is installed with a covert design.
12. Video camera with LCD monitor both inside and outside the vehicle provide rear viewing and monitoring

Protecting military and VIP convoys from the threat of Remote Control Improvised Explosive Devices (RCIEDs)-road-side bombs has become a challenge and task in many parts of the world.

Features
1. Using DDS Jamming technology to make the Frequency setting more precise
2. High efficient output power, long jamming radius
3. Slow start up design of circuit to make the device work stably.
4. Perfect Self Protection, Over Heat protection, Over current protection, High input Voltage and low Voltage protection, VSWR protection
5. Easy operation, using Wire Control Panel to monitor the system

Applications
1. Military Convoy
2. VIP Protection
3. RIOT Control
4. S.W.A.T Team
5. EOD Operations
6. Electronic countermeasure, etc

Power Amplifier Protection
A. Over Heat protection Thermal protector
B. Over current protection
C. High input Voltage and low Voltage protection
D. VSWR protection: against antenna miss-match including open and short circuit

Remote Control

Wire Control Panel available
A. Output power LCD Indication
B. Output power adjusting by LCD
C. Output power on/off per band
D. Jamming frequency setting by LCD Panel

Specifications:

Customized Isolating Signal Bandwidth

Wecome to do OEM/ODM, we can do customized frequency based above frequencies.

Shenzhen Times Starlight Technology Co.,Ltd, Established in 2001, is a professional enterprise focused on the deisgn ,development and production of signal jammers. It’s a subsidiary Hongkong Times Starlight Technology Co.,Ltd of  which focused on telecommunication security and defence products only. After 15 years' effort and development, Now we have become one of the leading phone signal jammer manufacturer and service provider. We are located in Shenzhen with convenient transportation access. All of our products comply with international quality standards and are greatly appreciated in a variety of different markets throughout the world.

We are one of the earlist signal jammer manufacturer in China for over 15 years. During the development of our business we have done many government projects. Rich experience have been acquired with the Prison Jamming projects, Police Ministry projects, Communication Ministry projects and Army projects. We also have established many cooperation with some other great telecommunication companies to finish every client’s special requirements. Such as signal frequency scanning, tracking, monitoring and jamming. Our Signal jammer can bolck almost all Wireless Remote Control Devices, Wireless Telecommunication Devices and some Wireless SPY Devices, etc. It means that any devices worked on 20MHz to 6.5G can be disabled by our Signal Jammers. Such as Remote control toy, Walkie Talkie, Cell phone, GPS tracker, Remote Control Bombs, Unmanned Plane, etc. The frequencies could be VHF, UHF, CDMA, WCDMA, GSM, DCS, PCS, LTE, WIMAX, GPS, WIFI, Bluetooth,Lojack, 3G, 4G, etc.

Times Starlight has a special professional R&D department. We have 9 RF Technicists and 3 software engineers. Some of them are from Huawei or ZTE. We also have cooperation with Huawei and ZTE to share some techlonogy to grow together. These make us be able to handle all kinds of customized products with various requirements.

Times Starlight's Mission is to make a safer telecommunication Environment for the wolrd. We hope we could always work on RF technology to protect people from unwanted disturb and hurt.

If you are interested in any of our service or would like to discuss a custom order, please feel free to contact us. We will show you all our advantages and let's grow together. Long term and friendly business relationship will be established because of your trust and our excellent service.
